Dereneville DAE-01-SP
dynamic - souverein - no limits
All features of the DAE-01CL are also shown in this drive unit. The DAE-01 SP drive unit does not shy away from any comparison. A tangible increased playing feeling. Just like with the little brother DAE-01 CL, we do not make any compromises in terms of synchronization and long- term stability. However, we have significantly expanded the functionality of this system. When developing the DAE-01 SP, our goal was: Precision, comfort, performance, enjoyment and fun If you ever thought it would be nice if... this drive unit will not disappoint you. We have implemented what is conceivable for the operation of a drive. Whether you want to drive a turntable with 500g or 70kg and all speeds 33.33, 45, 78 or 16.66, no problem with the DAE-01 SP... With this drive unit you will experience a tangible increase in your music playback in addition to all the features.
Dereneville | Rothert Strasse 8 | Lippstadt |ZIP-Code: 59555 | Tel: +49 (0)2941 6691118
IMPRESSUM
Disclaimer
Facts.
• Diameter 118mm • Case height 108 mm • Height feet 6 mm • Total height 135mm • Belt height approx.: 128 mm center belt • Weight 2.61kg • Motor power 30 W • Motor torque 45 mNm "heaviest" 60kg plate • Motor acceleration variably adjustable • Engine brake variably adjustable • Supply voltage 24 V External plug-in power supply 24V (included) • Current consumption operation 0.3A - 1A depending on the load • Current consumption idle < 200mA • Current consumption standby / off < 10mA • Display 1 4 x 7 segments, adjustable brightness • Buttons 6 On/Off, Pitch+, Pitch-, 33/16, 45, 78 • USB 1 For Modomania and SW service • Service Plug 1 Service and special function • Pulley 1 Dereneville Standard Pulley (included)Technical details
Speeds 4 33.33 45.00 78.00 and 16.66 Motion Care 1 care mode in off state when Motion Care is active After an adjustable waiting time (1 hour to 7 days), the DAE-01SP runs at a slow speed for an adjustable time For the care of the belt and all bearings. Pickups 3 hour meters for 3 pickups Sets 3 3 sets for operation on e.g. 3 different drives In each set are: Adjustable speeds 33.33 45.00 78.00 and 16.66 Adjustable acceleration and deceleration ramps Programmable hour meters for the belt and 3 pickups
